| Category | EDC7 | EDC17 |
|---|---|---|
| Manufacturer | Bosch | Bosch |
| Introduction Period | Approx. 2004–2012 | Approx. 2012–Present |
| Emission Compliance | Euro 4 ~ Euro 5 | Euro 6 |
| Applied Vehicles | MAN TGA, TGS, TGX (older models) | MAN TGS, TGX (Euro 6) |
| Applied Engines | D20, D26 (Common Rail), some D08 | D08, D20, D26, D38 |
| Base ECU | Bosch EDC7C32 / C36 | Bosch EDC17CV41 / CV52 etc. |
| Diagnostic Tools | MAN-cats II / III | MAN-cats III / Premium Tech Tool |
| OBD Functions | Limited | Full OBD II compliance |
| Item | Description |
|---|---|
| Rail Pressure Sensor | Fuel pressure control |
| Crank / Cam Sensor | Engine speed and ignition timing |
| NOx Sensor | For SCR control |
| DPF Differential Pressure Sensor | Detects DPF clogging |
| EGT Sensor | Monitors exhaust temperature |
| Throttle Pedal Sensor | Drive-by-wire system |
| AdBlue Dosing Valve | Precise urea injection control |
| Category | EDC7 | EDC17 |
|---|---|---|
| CAN Communication | Single CAN supported | Multi-CAN supported |
| Diagnostic Port | ISO 9141 / J1939 | J1939 + OBD II |
| Diagnostic Tools | MAN-cats II / III | MAN-cats III, external VCI possible |
| DTC Coverage | Limited | Detailed classification incl. Sub-DTCs |
| Data Logging | Basic | High-resolution logging (graph, real-time comparison, etc.) |
